Sanitary Aseptic Air SS GAS Vent Filter Housing

Share

The vent filter is specially designed for the purpose of eliminating bacteria in gas exchange in pharmaceutical and food industries.

Products Details

Sanitary Aseptic Air SS GAS Vent Filter Housing

Product Description

The vent filter is specially designed for the purpose of eliminating bacteria in gas exchange in pharmaceutical and food industries. The air in the tank can be separated from the outside by this filter. The air in the tank can be discharged smoothly, so that the microorganisms and particles outside the tank can not enter the tank.

Sanitary Aseptic Air SS GAS Vent Filter

Product Feature

1. The diameter of filter core is uniform and stable with low air resistance.

2. The precision of gas filtration is 0.01um, reaching 99.99% efficiency, which meets the aseptic requirements of GMP.

3. Interface with quick open type(clamp), filter cylinder is made of 304/316L. The inner surface is processed by polishing tech, Ra 0.28-0.6um. Treatment of outer surface can be designed according to requests.


Application:

1. Biological technology, fine chemical industry, Pharmaceutical field.

2. Food and beverage industry


Technical Parameter

MaterialFilter materialSS316L /SS304
O ring gasketEPDM,PTFE,Silicone, vi-ton
CartridgeStandardPTFE
PressureWorking pressure6 bar
TemperatureWorking temperature135℃
Sterilization temperature121℃≤30min
Surface treatmentFinish typePolishing
Surface finishInternal 0.3 μm, External 0.4 μm
Connectionclamp
Filter cartridge con.226
Length5"  10"   20"



Filter Choice

PTFE filter cartridge for the sterilization.

PP filter cartridge for non sterilization.
