YT-1P5S PP All-Plastic Fluid Filter Housing

Share

Yitong all-plastic fluid filter housing is made of imported PP material, adopted one-time injection molding technology. Whereby its great corrosive resistance, it is suited well in the filtration of many types of chemical fluids.

Products Details

Plastic Fluid Filter Housing

Product Description

Yitong all-plastic fluid filter housing is made of imported PP material, adopted one-time injection molding technology. Whereby its great corrosive resistance, it is suited well in the filtration of many types of chemical fluids.

YT-1P5S PP All-Plastic Fluid Filter Housing


Product Feature

1 PP material make it anti-corrosive

2 Great leakproofness

3 The thread connector makes it is easy to install and take apart.

4 Special design makes the filter cartridge stay stable in the filter.


Application

1 The corrosive fluids in chemical industry: acid, alkali, sulfuric acid, acetic acid, etc.

2 Low temperature fluids: liquid methane, liquid ammonia, etc.

3 Food and pharmaceutical industry: beer, beverage, raw medicine material, etc.


Technical Parameter


Material of the housing

PP

Working pressure

0.6Mpa

Working temperature

80℃

Volume

From 0.02 to 0.9 m³

Flow((viscosity=1cP))

10, 20, 40, 60, 100 m³/h

Inlet and outlet

DN50

Number of filter cartridges

1-20

Lengths of filter cartridges

10-80 inch
